125L MALTEZOS INOX / SAC 100X150
The MALTEZOS 125L Solar Water Heater is the ideal choice for those seeking an efficient, cost-effective, and environmentally friendly solution for producing hot water. Designed to meet the needs of small households with up to 2 members or holiday homes where hot water demand is lower, its use is limited during the summer months, and the system’s performance is higher due to seasonal conditions.
Stainless steel water tanks have significant advantages over others because they offer:
Excellent resistance to corrosion
Excellent durability in both low and high temperatures
Aesthetic perfection in the external finish
Pure and clean sanitary water
Significantly lower weight compared to enameled water tanks
MALTEZOS INOX stainless steel Solar Water Heaters are available in various types, including those with a standard or low base, as well as a base specifically designed for installation on tiled roofs, and are available with an optional serpentine for connection to the central heating system. Additionally, triple-energy models are available, which are suitable for operation in combination with central heating, offering maximum flexibility and efficiency.
i. Water storage tank made of stainless steel - INOX 316L HiMo.
ii. Tank insulation (polyurethane 70mm, 35-40Kg/m3).
iii. Outer casing made of stainless steel 304BA.
iv. Stainless steel 316L coil for supplementary energy source (e.g., central heating boiler) (only for triple-energy boilers - 3E).
Description
Technical Specifications
125L MALTEZOS INOX / SAC 100X150
Hot Water Storage Tank | |
|---|---|
Capacity (lt) | 116,5 |
Diameter (cm) | 52 |
Length (cm) | 111 |
Weight (empty) (kg) | 39,2 |
Anode protection Magnesium | Φ22x300mm |
Supplementary Heating Source | El Resistance 3.5 kW |
Insulation | PU 70mm-40kgr/m3 |
Recommended Operating Pressure | 5 atm |
Nominal pressure | 10 atm |
Collector | |
|---|---|
Collector type | FLAT |
Number of Collectors / Size (cm) | 1 / 100x150 |
Welding | Laser |
Number of risers | 9 |
Insulation (back | Glasswool 50mm |
Insulation (side) | Rockwool 20mm |
Sealant | EPDM |
Weight w/0 water | 26,5 |
Working pressure | 1,5 bar |
Test pressure | 15 bar |
Frame support | Hot Galvanised steel |
System weight empty (kg) | 94 |
System dimensions (cm) (HχLχW) | 170x107x170 |
