160L MALTEZOS INOX / 2SAC 90X150
Enhance your daily life with a 160L MALTEZOS solar water heater, ensuring savings, comfort, and eco-friendly performance! This water heater is ideal for providing hot water for everyday activities such as bathing, dishwashing, and laundry, fully covering the needs of a household with up to 4 members.
Stainless steel water tanks have significant advantages over others because they offer:
Excellent resistance to corrosion
Excellent durability in both low and high temperatures
Aesthetic perfection in the external finish
Pure and clean sanitary water
Significantly lower weight compared to enameled water tanks
MALTEZOS INOX stainless steel solar water heaters are available in various types, including those with a standard or low base, as well as a base specifically designed for installation on tiled roofs, and are available with an optional serpentine for connection to the central heating system. Additionally, triple-energy models are available, which are suitable for operation in combination with central heating, offering maximum flexibility and efficiency.
i. Water storage tank made of stainless steel - INOX 316L HiMo.
ii. Tank insulation (polyurethane 70mm, 35-40Kg/m3).
iii. Outer casing made of stainless steel 304BA.
iv. Stainless steel 316L coil for supplementary energy source (e.g., central heating boiler) (only for triple-energy boilers - 3E).
Description
Technical Specifications
160L MALTEZOS INOX / 2SAC 90X150
Hot Water Storage Tank | |
|---|---|
Capacity (lt) | 156,5 |
Diameter (cm) | 52 |
Length (cm) | 135 |
Weight (empty) (kg) | 51,7 |
Anode protection Magnesium | Φ22x300mm |
Insulation El Resistance | El Resistance 3.5 kW |
Insulation | PU 70mm-40kgr/m3 |
Recommended Operating Pressure | 5 atm |
Nominal pressure | 10 atm |
Collector | |
|---|---|
Collector type | FLAT |
Number of Collectors / Size (cm) | 2 / 90x150 |
Welding | Laser |
Number of risers | 8 |
Insulation (back) | Glasswool 50mm |
Insulation (side) | Rockwool 20mm |
Sealant | Κόλλα σιλικόνης / EPDM |
Weight w/0 water | 23 |
Working pressure | 1,5 bar |
Test pressure | 15 bar |
Frame support | Hot Galvanised steel |
System weight empty (kg) | 130 |
System dimensions (cm) (HχLχW) | 176x200x170 |
